The Mirror Adjustable Boxes
| Physical Specification | |
|---|---|
| Product Type | Gear |
| Item Group | 04 Recessed Spots Adjustable LED |
| Family | The Mirror Adjustable Boxes |
| Order Code | 51506B/W/W |
| Colour | White |
| Material | Die Cast |
| Shape | Rectangular |
| Length | 220mm |
| Width | 68mm |
| Height | 50mm |
| Cutout Hole Width | 212mm |
| Cutout Hole Height | 55mm |
| Recessed Ceiling | Yes |
| Depth Required | 70mm |
| Indoor | Yes |
| Adjustable | 1 Direction |
| Electrical Characteristics | |
| Gear | External-Included |
| Input Voltage | 220-240V |
| 50 Hz | Yes |
| 60 Hz | Yes |
| Safety Class | Class II |
| Power (Watts) | 20W |
| IP Rating | IP20 |
| Light Source | LED built in |
| Dimmable | No |
| F Mark | Yes |
| Input Type | Constant Current |
| Input Current | 500mA |
| Voltage | 35,7V |
| Safety Class | Class III |
| Power (Watts) | 17,85W |
| IP Rating | IP20 |
| Light Source | LED built in |
| LED Type | COB |
| LED Brand | Cree |
| LED Number | 5 |
| F Mark | Yes |
| Gear Type | Led Driver |
| Input Voltage | 220-240V |
| 50 Hz | Yes |
| 60 Hz | Yes |
| Power (Watts) | 12,5-20W |
| Power Factor | 0,9 |
| Constant Current | Yes |
| IP Rating | IP20 |
| Safety Class | Class II |
| Dimmable | No |
| Housing Material | Plastic |
| Output Terminal | Cable |
Опис
20W COB LED adjustable recessed Spot with dark chrome reflector.
Supplied with non-dimmable LED driver.
Complies with standard EN60598-1 and any other specific
standards.
